A1 A2 Cable Glands

Neutrical International's A1 A2 Cable Glands are designed to provide secure and reliable connections in industrial, marine, mining, and hazardous areas. Made from high-quality materials like brass and stainless steel, these glands ensure exceptional performance and durability, meeting the highest safety standards. Our A1 A2 Cable Glands are ideal for various applications, offering protection against environmental factors and mechanical stress.

Key Features of A1 A2 Cable Glands

  • High-Quality Materials: Constructed from premium brass and stainless steel for enhanced durability and longevity.
  • Superior Environmental Protection: Provides excellent resistance to environmental factors such as dust, water, and corrosion.
  • Easy Installation: Designed for quick and straightforward installation, saving time and reducing labor costs.
  • Wide Range of Sizes: Available in various sizes to accommodate different cable diameters and application needs.

Technical Details
Size 20 MM TO 90 MM S & L
Standard BS 6121
IP Rating IP66 & 68
Application Outdoor or indoor for use with all types of unarmored cable
Function A2 type glands provide a single, pull resistant seal on the outer, sheath of unarmored cable
Material Brass BS 2874 CZ121 PB3
Options Threads Metric, NPT, BSP & PG
Finish Natural Brass Finish, Nickel Finish
Accessories Matching Accessories, Available Like PVC Shrouds, Lock Nuts & Earth Tag
Operating Temp Standard Seals -20° C to +80° C

Specifications
CODE GLAND SIZE THREAD SIZE ‘B’ MINIMUM LENGHT
OF THREAD ‘C’ 		CABLE RANGE “A”
METRIC NPT MAX MIn
NI-A1-20S A1/A2 20S M20 1/2" 10 11.5 8
NI-A1-20L A1/A2 20L M20 1/2" 10 13.5 11
NI-A1-25S A1/A2 25S M25 3/4" 10 16.5 13
NI-A1-25L A1/A2 25L M25 3/4" 10 19.5 16
NI-A1-32L A1/A2 32L M32 1" 10 25.5 19
NI-A1-40S A1/A2 40S M40 1 1/4" 15 29 23
NI-A1-40L A1/A2 40L M40 1 1/4" 15 32 25
NI-A1-50S A1/A2 50S M50 1 1/2" 15 37 31.5
NI-A1-50L A1/A2 50L M50 2" 15 43 36.5
NI-A1-63S A1/A2 63S M63 2" 15 50 42.5
NI-A1-63L A1/A2 63L M63 2 1/2" 15 55 49.5
NI-A1-75S A1/A2 75S M75 2 1/2" 15 61 54.5
NI-A1-75L A1/A2 75L M75 3" 15 67 60.5
NI-A1-90 A1/A2 90 M90 3" 20 78 65

Why Choose Neutrical A1 A2 Cable Glands?

Choosing Neutrical International's A1 A2 Cable Glands means investing in quality, reliability, and performance. Our cable glands are meticulously engineered to meet the specific needs of various industries, ensuring secure and safe connections. We prioritize customer satisfaction by offering customized solutions, tailored to your unique requirements. Our rigorous quality control processes guarantee that every product meets the highest standards. Additionally, our expert team provides exceptional customer support and technical assistance, ensuring you receive the best solutions for your applications. Trust Neutrical International for cable glands that deliver unmatched performance and durability in the most demanding environments.
